Aluminum Windows & Doors
68 / 100 Heavy-Duty Sliding Door
Design, construction and specifications
Designs & details
2 visual references
Product specifications
Core specifications
- Main profile
- Primary aluminum T6063-T66
- Profile wall thickness
- 68 series: 3.0 mm; 100 series: 2.0 mm
- Glazing configuration
- 5+20A+5 mm
- Hardware
- BOGO hardware
Finishes & appearance
- Finish options
- Moonlight Grey, Soft-Touch Black
Construction & detailing
- Sash stile (mm)
- 68 / 100
- Frame width (mm)
- 2-track 126; 3-track 171
- Architrave width (mm)
- 120
- Architrave wall overlap (mm)
- 85
Specification source: EOUXIN Chinese catalog, pages 45, 46. Finish names are descriptive; confirm against an approved sample.
